Type
Single-lens reflex digital camera
Lens mount
Nikon F mount (with AF coupling and AF contacts)
Effective angle of view
Nikon DX format; focal length in 35 mm [135] format equivalent to approx. 1.5x that of lenses with FX format angle of view
Image sensor format
DX
Image sensor type
CMOS
Sensor size
23.5 mm x 15.7 mm
Total pixels
21.51 million
Dust-reduction system
Image sensor cleaning, Image Dust Off reference data (Capture NX-D software required)
Effective pixels
20.9 million
Image size (pixels)
DX (24×16) image area (L) 5568 x 3712 ( 20.6 million) (M) 4176 x 2784 ( 11.6 million) (S) 2784 x 1856 ( 5.1 million) 1.3x (18×12) image area (L) 4272 x 2848 ( 12.1 million) (M) 3200 x 2136 ( 6.8 million) (S) 2128 x 1424 ( 3 million) Photographs with image area of DX taken during movie recording (L) 5568 x 3128 ( 17.4 million) (M) 4176 x 2344 ( 9.7 million) (S) 2784 x 1560 ( 4.3 million) Photographs with image area of 1.3X taken during movie recording (L) 4272 x 2400 ( 10.2 million) (M) 3200 x 1800 ( 5.7 million) (S) 2128 x 1192 ( 2.5 million) Photographs taken during movie recording at a frame size of 3840 x 2160: 3840 x 2160 (8.2 million)
File format
NEF (RAW): 12 or 14 bit, lossless compressed or compressed JPEG: JPEG-Baseline compliant with fine (approx. 1 : 4), normal (approx. 1 : 8), or basic (approx. 1 : 16) compression; optimal quality compression available NEF (RAW) + JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats
Picture Control system
Auto, Standard, Neutral, Vivid, Monochrome, Portrait, Landscape, Flat ; selected Picture Control can be modified; storage for custom Picture Controls
Media
SD, SDHC (UHS-I compliant), SDXC (UHS-I compliant)
File system
DCF 2.0, Exif 2.31, PictBridge
Viewfinder
Eye-level pentaprism single-lens reflex viewfinder
Frame coverage
DX (24×16) image area: Approx. 100% horizontal and 100% vertical 1.3x (18×12) image area: Approx. 97% horizontal and 97% vertical
Magnification
Approx. 0.94x (50 mm f/1.4 lens at infinity, –1.0 m(*1))
Eyepoint
18.5mm (–1.0 m(*1); from center surface of viewfinder eyepiece lens)
Diopter adjustment
-2 to +1 m(*1)
Focusing screen
Type B BriteView Clear Matte Mark II screen with AF area brackets (framing grid can be displayed)
Reflex mirror
Quick return
Lens aperture
Instant return, electronically controlled
Compatible lenses
Compatible with AF NIKKOR lenses, including type G, E, and D lenses (some restrictions apply to PC lenses) and AI-P NIKKOR lenses and non-CPU AI lenses (M mode only). IX NIKKOR lenses, lenses for the F3AF, and non-AI lenses can not be used. The electronic rangefinder can be used with lenses that have a maximum aperture of f/5.6 or faster (the electronic rangefinder supports the center 1 focus point with lenses that have a maximum aperture of f/8 or faster).
Type
Electronically-controlled vertical-travel focal-plane mechanical shutter; electronic front-curtain shutter available in mirror up release mode
Speed
1/8000 to 30 s in steps of 1/3 or 1/2 EV, bulb, time, X250
Flash sync speed
X=1/250 s; synchronizes with shutter at 1/320 s or slower (flash range drops at speeds between 1/250 and 1/320 s)
Modes
S (single frame), CL (continuous low speed), CH (continuous high speed), Q (quiet shutter-release), QC (quiet continuous shutter-release), Self-timer, MUP (mirror up)
Approximate frame advance rate
Up to 8 fps • CL: 1 to 7 fps • CH: 8 fps Note: Frame rates assume continuous-servo AF, manual or shutter-priority auto exposure, a shutter speed of 1/250 s or faster, Release selected for Custom Setting a1 (AF-C priority selection), and other settings at default values.
Self-timer
2 s, 5 s, 10 s, 20 s; 1 to 9 exposures at intervals of 0.5, 1, 2, or 3 s
Remote control modes
Delayed remote, quick-response remote, remote mirror-up
Metering system
TTL exposure metering using RGB sensor with approximately 180K (180,000) pixels
Metering mode
Matrix: 3D color matrix metering III (type G, E, and D lenses); color matrix metering III (other CPU lenses) Center-weighted: Weight of approximately 75% given to 8 mm circle in center of frame. Diameter of circle can be changed to 6, 10, or 13 mm, or weighting can be based on average of entire frame (non-CPU lenses use 8-mm circle) Spot: Meters circle with diameter of about 3.5 mm (about 2.5% of frame) centered on selected focus point (on center focus point when non-CPU lens is used) Highlight-weighted: Available with type G, E, and D lenses
Range
(ISO 100, f/1.4 lens, 20 °C/68 °F) Matrix, center-weighted, or highlight-weighted metering: 0 to 20 EV Spot metering: 2 to 20 EV
Exposure meter coupling
CPU
Mode
Auto modes (auto; auto, flash off); scene modes (portrait; landscape; child; sports; close up; night portrait; night landscape; party/indoor; beach/snow; sunset; dusk/dawn; pet portrait; candlelight; blossom; autumn colors; food); special effects modes (night vision; super vivid; pop; photo illustration; toy camera effect; miniature effect; selective color; silhouette; high key; low key); programmed auto with flexible program (P); shutter-priority auto (S); aperture-priority auto (A); manual (M); U1 (user settings 1); U2 (user settings 2)
Exposure compensation
Can be adjusted by –5 to +5 EV in steps of 1/3 or 1/2 EV in P, S, A, M, SCENE, and EFFECTS modes
Exposure lock
Luminosity locked at detected value
ISO sensitivity (Recommended Exposure Index)
ISO 100 to 51200 in steps of 1/3 or 1/2 EV Can also be set to approx. 0.3, 0.5, 0.7, or 1 EV (ISO 50 equivalent) below ISO 100 or to approx. 0.3, 0.5, 0.7, 1, 2, 3, 4, or 5 EV (ISO 1640000 equivalent) above ISO 51200; auto ISO sensitivity control available
Active D-Lighting
Can be selected from Auto, Extra high, High, Normal, Low, or Off
Autofocus system
Nikon Advanced Multi-CAM 3500 II autofocus sensor module with TTL phase detection, fine-tuning, 51 focus points (including 15 cross-type sensors; f/8 supported by 1 sensor), and AF-assist illuminator (range approx. 0.5 to 3 m/1 ft 8 in. to 9 ft 10 in.)
Detection range
–3 to +19 EV (ISO 100, 20 °C/68 °F)
Lens servo
Continuous-servo AF (AF-C), Auto AF-S/AF-C selection (AF-A) , predictive focus tracking activated automatically according to subject status Manual focus (M): Electronic rangefinder can be used
Focus point
51 Can be selected from 51 or 11 focus points
AF-area mode
Single-point AF; 9-, 21-, or 51-point dynamic-area AF, 3D-tracking, group-area AF, auto-area AF
Focus lock
Focus can be locked by pressing shutter-release button halfway (single-servo AF) or by pressing AE-L/AF-L button
Built-in flash
Auto, portrait, child, close up, night portrait, party/indoor, pet portrait, super vivid, pop, photo illustration, toy camera effect: Auto flash with auto pop-up P, S, A, M, food: Manual pop-up with button release
Guide number
Approx. 12/39, 12/39 with manual flash (m/ft, ISO 100, 20 °C/68 °F)
Control
TTL: i-TTL flash control using RGB sensor with approximately 180K (180,000) pixels is available with built-in flash; i-TTL balanced fill-flash for digital SLR is used with matrix, center-weighted, and highlight-weighted metering, standard i-TTL fill-flash for digital SLR with spot metering
Mode
Auto, auto with red-eye reduction, auto slow sync, auto slow sync with red-eye reduction, fill-flash, red-eye reduction, slow sync, slow sync with red-eye reduction, rear-curtain with slow sync, rear-curtain sync, off; Auto FP High-Speed Sync supported
Flash compensation
-3 to +1 EV in steps of 1/3 or 1/2 EV
Flash-ready indicator
Lights when built-in flash or optional flash unit is fully charged; flashes after flash is fired at full output
Accessory shoe
ISO 518 hot-shoe with sync and data contacts and safety lock
Nikon Creative Lighting System (CLS)
i-TTL flash control, radio-controlled Advanced Wireless Lighting, optical Advanced Wireless Lighting, modeling illumination, FV lock, Color Information Communication, Auto FP High-Speed Sync, AF-assist for multi-area AF
Sync terminal
AS-15 sync terminal adapter (available separately)
White balance
Auto (2 types), incandescent, fluorescent (7 types), direct sunlight, flash, cloudy, shade, preset manual (up to 6 values can be stored, spot white balance measurement available during live view), choose color temperature (2500 K to 10,000 K), all with fine-tuning
Bracketing types
Exposure, Flash, White balance, ADL
Modes
Photo live view, Movie live view
Lens servo
Autofocus (AF): Single-servo AF (AF-S); full-time servo AF (AF-F) Manual focus (M)
AF-area mode
Face-priority AF, Wide-area AF, Normal-area AF, Subject-tracking AF
Autofocus
Contrast-detect AF anywhere in frame (camera selects focus point automatically when face-priority AF or subject-tracking AF is selected)
Metering system
TTL exposure metering using main image sensor
Metering mode
Matrix, center-weighted, or highlight-weighted
Frame size (pixels) and frame rate
3840 x 2160 (4K UHD); 30p (progressive), 25p, 24p 1920 x 1080; 60p, 50p, 30p, 25p, 24p 1280 x 720; 60p, 50p Actual frame rates for 60p, 50p, 30p, 25p, and 24p are 59.94, 50, 29.97, 25, and 23.976 fps respectively; high quality available at all frame sizes, normal quality available at all sizes except 3840 x 2160
File format
MOV, MP4
Video compression
H.264/MPEG-4 Advanced Video Coding
Audio recording format
Linear PCM, AAC
Audio recording device
Built-in stereo or external microphone; sensitivity adjustable
ISO sensitivity (Recommended Exposure Index)
Mode M: Auto ISO sensitivity control (ISO 100 to Hi 5) available with selectable upper limit; manual selection (ISO 100 to 51200 in steps of 1/3 or 1/2 EV) with additional options available equivalent to approximately 0.3, 0.5, 0.7, 1, 2, 3, 4, or 5 EV (ISO 1640000 equivalent) above ISO 51200 Modes P, S, and A: Auto ISO sensitivity control (ISO 100 to Hi 5) with selectable upper limit Night vision (EFFECT) mode: Auto ISO sensitivity control (ISO 100 to Hi 5) Other modes: Auto ISO sensitivity control (ISO 100 to 12800)
Active D-Lighting
Can be selected from Same as photo settings, Extra high, High, Normal, Low, or Off
Other options
Index marking, time-lapse movies, electronic vibration reduction
Monitor size
8 cm ( 3.2 –in.) diagonal
Monitor type
tilting TFT touch-sensitive LCD with 170° viewing angle, approximately 100% frame coverage, manual monitor brightness control, and an eye-sensor controlling display on/off
Monitor resolution
Approx. 922 k-dot (VGA)
Playback
Full-frame and thumbnail (4, 9, or 72 images or calendar) playback with playback zoom, playback zoom cropping, movie playback, photo and/or movie slide shows, histogram display, highlights, photo information, location data display, picture rating, and auto image rotation
USB connector
Hi-Speed USB with Micro-B connector; connection to built-in USB port is recommended
HDMI output connector
Type C HDMI connector
Audio input
Stereo mini-pin jack (3.5 mm diameter; plug-in power supported)
Audio output
Stereo mini-pin jack (3.5 mm diameter)
Accessory terminal
Wireless remote controllers: WR-1, WR-R10 (available separately) Remote cord: MC-DC2 (available separately) GPS unit: GP-1/GP-1A (available separately)
Standards
IEEE 802.11b, IEEE 802.11g
Operating frequency
2412 to 2462 MHz (channels 1 to 11)
Maximum output power
8.4 dBm (EIRP)
Security
Authentication: Open system, WPA2-PSK
Communication protocols
Bluetooth Specification Version 4.1
Range (line of sight)
Approximately 10 m (32 ft) without interference; range may vary with signal strength and presence or absence of obstacles
Supported languages
Arabic, Bengali, Bulgarian, Chinese (Simplified and Traditional), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hindi, Hungarian, Indonesian, Italian, Japanese, Korean, Marathi, Norwegian, Persian, Polish, Portuguese (Portugal and Brazil), Romanian, Russian, Serbian, Spanish, Swedish, Tamil, Telugu, Thai, Turkish, Ukrainian, Vietnamese
Battery
One EN-EL15a rechargeable Li-ion battery
AC adapter
EH-5c AC adapter; requires EP-5B power connector (available separately)
Tripod socket
1/4–in. (ISO 1222)
Dimensions (W x H x D)
Approx. 135.5 x 104 x 72.5 mm ( 5.4 x 4.1 x 2.9 in.)
Weight
Approx. 720 g ( 1 lb 9.4 oz ) with battery and memory card but without body cap; approx. 640 g (1 lb 6.6 oz; camera body only)
Operating environment
Temperature: 0 °C to 40 °C (+32 °F to 104 °F) Humidity: 85% or less (no condensation)
Supplied accessories
DK-28 Rubber Eyecup, BF-1B Body Cap, EN-EL15a Rechargeable Li-ion Battery with terminal cover, MH-25a Battery Charger (comes with either an AC wall adapter or power cable of a type and shape that varies with the country or region of sale), DK-5 Eyepiece Cap, AN-DC3 BK Strap, E20 USB Cable
1. Unless otherwise stated, all measurements are performed in conformity with Camera and Imaging Products Association (CIPA) standards or guidelines. All figures are for a camera with a fully-charged battery. Nikon reserves the right to change the appearance and specifications of the hardware and software described in these specifications at any time and without prior notice. Nikon will not be held liable for damages that may result from any mistakes that this specifications may contain.
