Specs
General
-
Dimensions
-
144.2×44.4×33.5 mm (L×W×H)
-
Weight
-
190.5 g
-
Number of Microphones
-
3
-
Touchscreen
-
Size: 2.0 inches
Resolution: 556×314
Brightness: 1000 nits
-
Supported SD Cards
-
microSD (up to 1 TB)
-
Recommended microSD Cards
-
Recommended models:
Lexar Silver Plus 64GB U3 A2 V30 microSDXC
Lexar Silver Plus 128GB U3 A2 V30 microSDXC
Lexar Silver Plus 256GB U3 A2 V30 microSDXC
Lexar Silver Plus 512GB U3 A2 V30 microSDXC
Lexar Silver Plus 1TB U3 A2 V30 microSDXC
Kingston CANVAS GO! Plus 64GB U3 A2 V30 microSDXC
Kingston CANVAS GO! Plus 128GB U3 A2 V30 microSDXC
Kingston CANVAS GO! Plus 256GB U3 A2 V30 microSDXC
Kingston CANVAS GO! Plus 512GB U3 A2 V30 microSDXC
Kingston CANVAS GO! Plus 1TB U3 A2 V30 microSDXC
Gimbal
-
Controllable Range
-
Pan: -235° to 58°
Tilt: -120° to 70°
Roll: -45° to 45°
-
Mechanical Range
-
Pan: -240° to 63°
Tilt: -180° to 98°
Roll: -220° to 63°
-
Max Controllable Speed
-
180.0°/s
-
Angular Vibration Range
-
±0.005°
Camera
-
Sensor
-
1-inch CMOS
-
Lens
-
Format Equivalent: 20 mm
Aperture: f/2.0
Focus Range: 0.2 m to ∞
-
ISO Range
-
Photo: 50-12800
Video: 50-12800
Low-Light Video: 50-25600
Slow Motion: 50-12800
-
Electronic Shutter Speed
-
Photo: 1/8000-4 s
Video (Auto): 1/8000 s to the limit of frames per second
Video (M): 1/8000-1/4 s
-
Max Image Size
-
16:9, 7680×4320
1:1, 6144×6144
-
Zoom
-
Digital Zoom
Photo: 7680×4320, 2×
Video: 1080p, 4×; 3K, 4×; 4K, 4×
UVC & DP: 4K, 4×
Livestream: 1080p, 4×
Low Light/Slow Motion/Timelapse: Not available
-
Still Photography Modes
-
Single Shot: Approx. 37 MP
Countdown: Off/0.5/1/2/3/5/10 s
Panorama: 180°, 3×3
-
Normal Video
-
4K (16:9): 3840×2160@24/25/30/48/50/60fps
1080p (16:9): 1920×1080@24/25/30/48/50/60fps
3K (9:16): 1728×3072@24/25/30/48/50/60fps
1080p (9:16): 1080×1920@24/25/30/48/50/60fps
-
Slow Motion
-
4K (16:9): 3840×2160@100/120/200/240fps
1080p: 1920×1080@120/240fps
-
Hyperlapse
-
4K/1080p@25/30fps: Auto/×2/×5/×10/×15/×30
-
Timelapse
-
4K/1080p@25/30fps
Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40/60 s
Duration: 5/10/20/30 mins, 1/2/3/5/10/∞ hours
-
Motionlapse
-
4K/1080p@25/30fps
Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40/60 s
Duration: 5/10/20/30 mins, 1/2/3/5/10 hours
Supports setting four positions
-
Low-Light Video
-
4K (16:9): 3840×2160@24/25/30fps
1080p: 1920×1080@24/25/30fps
-
Max Video Bitrate
-
180 Mbps
-
Supported File System
-
exFAT
-
Photo Format
-
JPEG/DNG/JPEG+DNG
-
Video Format
-
MP4 (HEVC)
-
Built-in Storage Capacity
-
The camera has 107 GB of built-in storage. The storage capacity can be expanded by inserting a microSD card.
-
Audio Output
-
48 kHz 16-bit; AAC
Battery
-
Type
-
Li-ion
-
Capacity
-
1545 mAh
-
Energy
-
11.95 Wh
-
Voltage
-
7.74 V
-
Operating Temperature
-
0° to 40° C (32° to 104° F)
-
Charging Temperature
-
5° to 45° C (41° to 113° F)
-
Operating Time
-
240 mins
Tested at room temperature of 25° C (77° F) and 1080p/24fps (16:9), with Wi-Fi off and screen off. This data is for reference only.
-
Charging Time
-
18 mins to 80%; 32 mins to 100%
Tested in a laboratory environment with the DJI 65W Portable Charger (sold separately).
Connection
-
Wi-Fi Operating Frequency
-
2.400-2.4835 GHz
5.150-5.250 GHz
5.725-5.850 GHz
-
Wi-Fi Protocol
-
802.11 a/b/g/n/ac/ax
-
Wi-Fi Transmitter Power (EIRP)
-
2.4 GHz:
< 20 dBm (CE/SRRC/MIC)5.1 GHz:
< 23 dBm (SRRC)
< 20 dBm (CE)5.8 GHz:
< 23 dBm (SRRC)
< 14 dBm (CE)
-
Bluetooth Operating Frequency
-
2.400-2.4835 GHz
-
Bluetooth Transmitter Power (EIRP)
-
< 14 dBm
-
Bluetooth Protocol
-
BLE 5.4, BR/EDR
